Mono Bifacial Panel
Jinko 615W Tiger Neo JKM615N-66HL4M-BDV Bifacial Solar Panel
Key Facts
| Category | Solar Panel |
|---|---|
| Brand | Jinko |
| Capacity | 615W |
| Warranty | 25 years |
Features
- ✅Brand: Jinko Solar
- ✅ Model: JKM615N-66HL4M-BDV
- ✅ SREDA Approved (Net Metering Program)
- ✅ 615W bifacial N-type TOPCon solar panel
- ✅ 132 cells (66×2) with dual-glass construction
- ✅ 22.77% module efficiency
- ✅ 5400Pa snow load / 2400Pa wind load
- ✅ 12-year product warranty / 30-year power warranty
- ✅ 0~+3% positive power tolerance
- ✅ SMBB & HOT 3.0 technology with Anti-PID guarantee
Product Details
Technical Specifications
| Parameter | Value |
|---|---|
| Mechanical Characteristics | |
| Cell Type | N-type Mono-crystalline |
| No. of Cells | 132 (66×2) |
| Dimensions (L × W × H) | 2382 × 1134 × 30 mm |
| Weight | 32.4 kg |
| Front Glass | 2.0 mm, Anti-reflection Coating |
| Back Glass | 2.0 mm, Heat Strengthened Glass |
| Frame | Anodized Aluminium Alloy |
| Junction Box | IP68 Rated |
| Protection Class | Class III |
| IEC Fire Type | Class C |
| Connector Type | JK03M / MC4 / Others (MC4 and MC4-EVO2 available upon request) |
| Output Cables | 4.0 mm² (+): 400 mm, (-): 200 mm or Customized Length |
| Packaging Configuration | |
| Pallet Dimensions | 2396 × 1110 × 1251 mm |
| Packing Detail | 36 pcs/pallet, 72 pcs/stack, 720 pcs/40’HQ Container |
| Specifications (STC) | |
| Maximum Power (Pmax) | 615W |
| Maximum Power Voltage (Vmp) | 40.60V |
| Maximum Power Current (Imp) | 15.15A |
| Open-circuit Voltage (Voc) | 48.88V |
| Short-circuit Current (Isc) | 16.02A |
| Module Efficiency STC | 22.77% |
| Power Tolerance | 0 ~ +3% |
| Temperature Coefficient of Pmax | -0.29 %/℃ |
| Temperature Coefficient of Voc | -0.25 %/℃ |
| Temperature Coefficient of Isc | 0.045 %/℃ |
| Specifications (BNPI) | |
| Maximum Power (Pmax) | 679W |
| Maximum Power Voltage (Vmp) | 40.59V |
| Maximum Power Current (Imp) | 16.73A |
| Open-circuit Voltage (Voc) | 48.86V |
| Short-circuit Current (Isc) | 17.70A |
| Application Conditions | |
| Level T98 | ≤ 70℃ |
| Operating Temperature Range | -40℃ ~ +70℃ |
| Maximum System Voltage | 1500 VDC (IEC) |
| Maximum Series Fuse Rating | 35A |
| Bifaciality Coefficients | φVoc: 98±5%, φIsc: 80±5%, φPmax: 80±5% |
| Mechanical Loading | |
| Front Side Maximum Static Loading | 5400Pa |
| Rear Side Maximum Static Loading | 2400Pa |
STC: Irradiance 1000W/m², Cell Temperature 25°C, AM=1.5
BNPI: Irradiance: Front 1000W/m², Rear 135W/m², Cell Temperature 25°C, AM=1.5
*Short-term up to 85°C; higher operation requires IEC TS 63126 testing.
Advanced Technology
The Jinko 615W Tiger Neo JKM615N-66HL4M-BDV features cutting-edge N-type TOPCon technology with 132 cells (66×2) for superior performance and reliability:
- N-Type TOPCon Technology: Lower LID/LeTID degradation and better low-light performance compared to conventional P-type modules.
- Dual-Sided Power Generation: Bifacial design captures light on both sides, significantly reducing LCOE.
- SMBB Technology: Better light trapping and current collection to improve module power output and reliability.
- HOT 3.0 Technology: JinkoSolar’s advanced technology for better reliability and efficiency.
- Anti-PID Guarantee: Minimizes degradation caused by PID phenomena through optimized cell production technology and material control.
Warranty & Certifications
The Jinko 615W Tiger Neo JKM615N-66HL4M-BDV comes with comprehensive warranty coverage and certifications:
- 12-Year Product Warranty: Full coverage for manufacturing defects.
- 30-Year Linear Power Warranty: 87.4% of nominal power guaranteed at year 30.
- First-Year Degradation: ≤1% for maximum initial performance.
- Annual Degradation (Year 2-30): ≤0.40% for long-term reliability.
- Certifications: IEC61215:2021, IEC61730:2023, IEC61701, IEC62716, IEC60068, IEC62804, ISO9001:2015, ISO14001:2015, ISO45001:2018, TÜV SÜD, CE, PV CYCLE.
Frequently Asked Questions (FAQ)
Q1. What is the maximum power output of the Jinko 615W Tiger Neo JKM615N-66HL4M-BDV?
The maximum power output is 615W with module efficiency of 22.77%.
Q2. What technology does this panel use?
It features N-type TOPCon technology with 132 cells (66×2) and advanced HOT 3.0 technology.
Q3. What is the warranty period?
It comes with a 12-year product warranty and a 30-year linear power warranty (87.4% at year 30).
Q4. What is the maximum system voltage?
The maximum system voltage is 1500 VDC (IEC).
Q5. What is the power tolerance?
The power output tolerance is 0~+3% positive.
Q6. What are the mechanical loading capacities?
Front side: 5400Pa, Rear side: 2400Pa.
Q7. Is this panel bifacial?
Yes, it features a bifacial dual-glass design with 80±5% bifaciality for additional rear-side power generation.
Q8. What is the operating temperature range?
-40°C to +70°C (short-term up to 85°C with IEC TS 63126 testing).
Q9. What certifications does it have?
It is certified to IEC61215:2021, IEC61730:2023, IEC61701, IEC62716, IEC60068, IEC62804, ISO9001, ISO14001, and ISO45001.
Q10. What is the connector type?
It features JK03M / MC4 connectors, with MC4 and MC4-EVO2 available upon request.
Download Datasheet | For manufacturer details, see the official page: Jinko 615W Tiger Neo JKM615N-66HL4M-BDV
