Jinko
Solar Panel
৳ 13,500.00
৳ 14,900.00
-9%
Mono Bifacial Panel
Jinko 625W Bifacial With Dual Glass Solar Panel
Key Facts
| Category | Solar Panel |
|---|---|
| Brand | Jinko |
| Capacity | 620W |
| Warranty | 25 years |
Features
- Cell Type: N-Type Monocrystalline | 132 Cells (66×2) | Bifacial Dual-Glass Design
- Power Output (Pmax): 625W | Module Efficiency: 23.14% | Power Tolerance: 0~+3%
- Voltage (Vmp / Voc): 40.88V / 49.28V | Current (Imp / Isc): 15.29A / 16.14A
- Max System Voltage: 1500VDC (IEC) | Max Series Fuse: 35A | Bifacial Factor: 80±5%
- Build: 2.0mm Anti-Reflection Front Glass | 2.0mm Heat-Strengthened Back Glass | Anodized Aluminium Alloy Frame | IP68 Junction Box | Output Cable: 4.0mm²
- Load & Temperature: Operating Temp: -40°C~+85°C | Temp. Coefficient (Pmax): -0.29%/°C
- Dimensions & Weight: 2382 × 1134 × 30 mm | 32.4 kg
Product Details
| Parameter | Specification |
|---|---|
| Cell Type | N-type Mono-crystalline |
| No. of Cells | 132 (66×2) |
| Dimensions | 2382×1134×30 mm |
| Weight | 32.4 kg |
| Front Glass | 2.0 mm, Anti-reflection Coating |
| Back Glass | 2.0 mm, Heat Strengthened Glass |
| Frame | Anodized Aluminum Alloy |
| Junction Box | IP68 Rated |
| Protection Class | Class II |
| IEC Fire Type | Class C |
| Output Cables | 4.0 mm² (+): 400 mm, (-): 200 mm or Customized Length |
Packaging Configuration
| Item | Details |
| Pallet Dimensions | 2396×1110×1251 mm |
| Packing Detail | 36 pcs/pallets, 72 pcs/stack, 720 pcs/40’HQ Container (Two Pallets One Stack) |
Specifications (STC)
STC: Irradiance 1000W/m², Cell Temperature 25°C, AM = 1.5
| Parameter | 600 | 605 | 610 | 615 | 620 | 625 |
| Maximum Power – Pmax (Wp) | 600 | 605 | 610 | 615 | 620 | 625 |
| Maximum Power Voltage – Vmp (V) | 40.16 | 40.31 | 40.46 | 40.60 | 40.74 | 40.88 |
| Maximum Power Current – Imp (A) | 14.94 | 15.01 | 15.08 | 15.15 | 15.22 | 15.29 |
| Open-circuit Voltage – Voc (V) | 48.28 | 48.48 | 48.68 | 48.88 | 49.08 | 49.28 |
| Short-circuit Current – Isc (A) | 15.84 | 15.90 | 15.96 | 16.02 | 16.08 | 16.14 |
| Module Efficiency STC (%) | 22.21 | 22.40 | 22.58 | 22.77 | 22.95 | 23.14 |
| Power Tolerance | 0 ~ +3 % | |||||
| Temperature Coefficients of Pmax | -0.29 %/°C | |||||
| Temperature Coefficients of Voc | -0.25 %/°C | |||||
| Temperature Coefficients of Isc | 0.045 %/°C |
Specifications (NOCT)
NOCT: Irradiance 800W/m², Ambient Temperature 20°C, AM = 1.5, Wind Speed 1m/s
| Parameter | 600 | 605 | 610 | 615 | 620 | 625 |
| Maximum Power – Pmax (Wp) | 453 | 457 | 461 | 464 | 468 | 472 |
| Maximum Power Voltage – Vmp (V) | 37.60 | 37.67 | 37.92 | 38.10 | 38.25 | 38.44 |
| Maximum Power Current – Imp (A) | 12.05 | 12.10 | 12.15 | 12.19 | 12.24 | 12.28 |
| Open-circuit Voltage – Voc (V) | 45.86 | 46.05 | 46.24 | 46.43 | 46.62 | 46.81 |
| Short-circuit Current – Isc (A) | 12.79 | 12.83 | 12.88 | 12.93 | 12.98 | 13.03 |
Application Conditions
| Parameter | Specification |
| Operating Temperature | -40°C ~ +85°C |
| Maximum System Voltage | 1500 VDC (IEC) |
| Maximum Series Fuse Rating | 35 A |
| Nominal Operating Cell Temperature – NOCT | 45±2 °C |
| Refer. Bifacial Factor | 80±5 % |
