Rahimafrooz
Lithium Battery
৳ 95,000.00
৳ 105,000.00
-10%
Lithium Battery with Prismatic Cell
- Powerful and Reliable - Intelligent BMS - Environment Friendly - Support Parallels and Series Connection - Built-in Fire Protection System - New Grade A Cells
Key Facts
| Category | Lithium Battery |
|---|---|
| Brand | Rahimafrooz |
| Capacity | 25.6V 105ah |
| Warranty | 60 months |
| Life Cycle | 6000 cycles |
Features
- Stackability: Supports up to 16* batteries in parallel.
- Long Lifecycle: 6000* cycles for extended durability.
- Smart Display: LCD screen for real-time monitoring.
- Communication Ports: RS485 & CAN for integration with smart systems.
- High Continuous Current discharge for heavy loads.
Product Details
| Specification | Attributes |
| Nominal Voltage | 25.6V |
| Nominal Capacity @ 25°C | 100AH |
| Nominal Energy @ 25°C | 2560WH |
| Battery Cell Type | Prismatic LiFePO4 (200Ah) |
| Configuration (*S*P) | 8S1P |
| Max. Continuous Charge Current @ 25°C | 100A |
| Max. Pulse Charge Current @ 25°C. 10s | 120A |
| Max. Continuous Discharge Current @ 25°C | 100A |
| Max. Pulse Discharge Current @ 25°C. 10s | 120A |
| DC Resistance | ≤10mΩ |
| Full Charged Voltage | 29.2V |
| Discharge Cut-off Voltage | 21.2V |
| Operate Temperature Range | Charge 0°C ~ 45°C |
| Humidity (Non-condensing) | Max. 95% |
| Dimension (mm) | 522*240*218 mm |
| Net Weight (Kg) | 19.65 Kg |
| Terminal Type | Screw Terminal |
| Cover Sealing Type | Screw Sealing |
| Cycle Life | 80% DOD Cycles @ 25°C, 1C: >3000 times |
| Battery Cell | New grade A cells |
| Warranty | 5 years |
| Series and Parallel Function | Available to make in series and parallels to get 24V, 36V, 48V |
