Sun Byte
Lithium Battery
৳ 65,000.00
৳ 78,500.00
-17%
Lithium Battery with Prismatic Cell
Higher specific energy Easy to install Long cycle life Support parallel operation Environment friendly Support deep customization
Key Facts
| Category | Lithium Battery |
|---|---|
| Brand | Sun Byte |
| Capacity | 2.56KWH |
| Warranty | 60 months |
| Life Cycle | 6000 cycles |
Features
- - Powerful and Reliable
- - Intelligent BMS
- - Environment Friendly
- - Support Parallels and Series Connection
- - Built-in Fire Protection System
- - New Grade A Cells
Product Details
| Specification | Attributes |
| Nominal Voltage | 12.8V |
| Nominal Capacity @ 25°C | 200AH |
| Nominal Energy @ 25°C | 2560WH |
| Battery Cell Type | Prismatic LiFePO4 (200Ah) |
| Configuration (*S*P) | 4S1P |
| Max. Continuous Charge Current @ 25°C | 100A |
| Max. Pulse Charge Current @ 25°C. 10s | 120A |
| Max. Continuous Discharge Current @ 25°C | 100A |
| Max. Pulse Discharge Current @ 25°C. 10s | 120A |
| DC Resistance | ≤10mΩ |
| Full Charged Voltage | 14.6V |
| Discharge Cut-off Voltage | 10.6V |
| Operate Temperature Range | Charge 0°C ~ 45°C |
| Humidity (Non-condensing) | Max. 95% |
| Dimension (mm) | 522*240*218 mm |
| Net Weight (Kg) | 18.95 Kg |
| Terminal Type | Screw Terminal |
| Cover Sealing Type | Screw Sealing |
| Cycle Life | 80% DOD Cycles @ 25°C, 0.5C: >3000 times |
| Battery Cell | New grade A cells |
| Warranty | 3 years |
| Series and Parallel Function | Available to make in series and parallels to get 24V, 36V, 48V |
